ABOUT US

Established in 1980, Hing Tai began as a company specializing in office renovation works, aluminum windows, suspended ceiling and partitions work. In 1983, Hing Tai ventured into manufacturing workstations and partitions system. In 2002, Pyrofire (M) Sdn. Bhd. have started the business and services to provide a passive fire protection in which glazing for life become the motive of the company.

Pyrofire (M) Sdn. Bhd. activities include trading and installation of these fire resistant glass to fulfill the rules and regulation by local building code and local fire code. As Pyrofire (M) Sdn. Bhd. been actively participate/organize in exhibition, seminar, company visit presentation to promote the fire resistant glass and raise the awareness of fire safety towards public.As an ISO9001: 2008 certified company; Pyrofire (M) Sdn. Bhd. is committed to achieve manufacturing excellence and superior quality products in fulfilling clients' needs. We pride ourselves for the certificated fire resistant glazing specialist company that responds to the growing demand for safer and affordable in fire resistant glazing system.

FIRE RESISTANCE GLASS

Fire-resistant glass solutions. Tried, tested, trusted.


Do you need more information?

EMAIL US

FIRE RESISTANCE GLASS INFORMATION

Fire resistant glass and glazing system used as a part of transparent passive fire protection system as a barrier to smoke, hot gases and flame, as well as effective insulation from the heart of a blaze. Providing robust fire protection sheild and to enable safe egress from building or structure while providing greater visibility and high quality natural lighting.

Fire resistant glass must always be used as part of tested and approved glazing system. Thus to achieve full integrity, insulation and stability within/ beyond the rating period.

As a certified fire resistant glass and glazing system, the system have been fully tested under BS476: Part 22: 1987 and EN1634-1:2014 and being approved and certified by fire authority, FRDM.

  • Protection against radiant and confuctive heat transfer.
  • Barrier to flames smoke and hot gas propagation.
  • Fire-resistant for up to 2 hours with required hose stream test.
  • Impact safety-rated meet Class A acc. BS6206/Class 1(B) 1 acc. EN12600.
  • Exceptional opacity quality, wireless and virtually distortion free.
  • For Interior and exterior application.
  • Bullet resitance rating up to BR4 S acc. EN1063.
  • Resistance against manual attack rating up to P2A/P6B acc. EN356.
  • Multi-laminate with intumescent layer.

TERMINOLOGY

Intergrity (E)

The ability of a specimen of a separating element to contain a fire to specified criteria for collapse, freedom from holes, cracks and fissures and sustained flaming on the unexposed face.

Insulation (I)

The ability of a specimen of a separating element to restric: the temperature rise of the unexposed face to below specified levels. Temperature rise on the unexposed fire side shall not be more than 140°C (average value) or 180°C (maximum individual value) above ambient temperature.

Stability (S)

Structure able to remain standing without collapse within specific period.

BEHAVIOUR

Glass materials used in construction and the manner in which they respond to fire, has a great bearing on how a structure or room will respond to fire. It is therefore important to develop an understanding of the behaviour of glass structural materials subjected to fire in terms of both the heat transfer characteristics of the glass and its response to heating. The following demonstrates the behaviour in fire of the our glass products.

INITIAL OF FIRE TEST

AFTER 2-3 MINUTES

AFTER INTUMESCENSE

FEATURED

Benefits and Uniqueness


FIRE RESISTANCE

Ability to resist fire to penetrate to adjacent compartment within specific period of time.

IMPACT RESISTANCE

Ability to withstand levels of impact forces up to Class A or 1(B)1 according to BS 6206 and EN 12600 respectively.

HEAT BARRIER

Reduce radiant and conductive heat transfer and fully insulated in the event of fire.

PRE-FABRICATED GLAZING SYSTEM

Glazing systems are pre-fabricated in factory to ensure quality with QC and QA team.

EASE OF INSTALLATION

Glazing systems is designed and built to reduce hassle on installation onto various field of applications/ wall types.

ENVIRONMENT FRIENDLY

Preserving our mother earth, green material in used to reduce carbon footprint.

WEATHER RESISTANCE

Material in used able to withstand exposure to weather without damage/ mold.

TERMITE RESISTANCE

Composite based material in used prevents humidity especially termite attack.

SMOKE CONTROL

Smoke seal is available to contain smoke for exposure risk to occupants.

ACOUSTIC CONTROL

Sound reduction to reduce transfer of sound wave up to 44 dB.

GREATER VISIBILITY

The use of glass enlarge the area for viewing and provide better visual appeal with nonwired and extra clear glass.

DECORATIVE GLASS


PROFILIT WAVE

Wave

Clear (without ornament)

Slim Line

Macro

Micro

PROFILIT

Decorative Glass enables you to add style and elegance to your home incorporating a range of options such as: Georgian or cottage bars, stained glass, leaded lights, bevels and brilliant cut glass to create a distinctive look. All are available in glazing units, to create a distinctive look

Uniqueness & Benefits

  • Up to 5.7 meter length.
  • Can be tempered or with heat soaked.
  • Provides high light diffusion.
  • Can be attained in large curtain walling sizes.
  • Can be fitted in single or double walls.
  • Available in several surface texture,colors.
  • Allows the construction of curved walls.
  • Rapid and easy maintenance and replacement.

SARAH'S ART GLASS

For more information please click on the button below to get more information about Sarah's Art Glass. (Art Glass, Textured Glass, Fusion Glass, Curve Glass, Decorative Glass)
